Power Mixer PMP1000 Behringer

The EUROPOWER PMP1000 powered audio mixer delivers 500 Watts of massive power and incredible performance through new-generation amplifier technology, crystal-clear sound, plus an ultra-compact and lightweight design. Other key features are the 24-bit stereo FX processor, IMP (Invisible Mic Preamp) mic preamps, Voice Canceller that' s handy for karaoke applications. Get massive power and great sound in a lightweight power mixer package. Please note that this mixer requires speaker cables with Speakon connectors.

Features

Ultra-compact 2 x 250-Watt stereo powered mixer (500 Watt bridged mode)
Revolutionary amplifier technology: enormous power, incredible sonic performance and super-light weight
Ultra-compact design at nearly half the weight of conventional powered mixers means no more lugging around dead weight
12-channel mixer section features 4 mono and 4 stereo channels, 2 additional stereo inputs plus separate tape returns
Studio-grade 24-bit stereo FX processor with 100 awesome presets including reverb, chorus, flanger, delay, pitch shifter and various multi-effects
Revolutionary FBQ Feedback Detection system instantly reveals critical frequencies for easy feedback removal
6 high-quality mic preamps (4 IMP "Invisible" Mic Preamps) with switchable +48 V phantom power for condenser microphones
Effective, extremely musical 3-band EQ, switchable Low cut filter and Clip LEDs on all mono channels
7-band graphic EQ allows precise frequency correction of monitor or main outputs
Voice Canceller function removes singer's voice from recordings for Karaoke applications
Selectable stereo (main L/R), double mono (main/monitor) or bridged mono amplifier operation mode
Standby switch mutes all mic channels during breaks while background music is provided via tape inputs
Breathtaking XPQ 3D stereo surround effect for more vitality and enhanced stereo image
Adjustable stereo CD/Tape input for connecting external signal sources
Speakon output connectors

EUROPOWER PMP1000 Powered Mixer Specifications:

DSP
Converter: 24-Bit Delta-Sigma, 64/128-times oversampling
Dynamics D/A: 90 dB
Sampling rate: 46.875 kHz Delay Time
Delay time: max. 5 s
Signal run time (Line In - Line Out): approx. 1.5 ms

Display type: dual 7-segment LED
Amplifier output power:
RMS @ 1 % THD (sine wave), both channels driven:
8 Ohms per channel: 90W
4 Ohms per channel: 130W
RMS @ 1 % THD (sine wave), bridged mode:
8 Ohms: 200W
Peak Power, both channels driven:
8 Ohms per channel: 135W
4 Ohms per channel: 250W
Peak Power, bridged mode:
8 Ohms: 500W

Power Supply (EU/A)
Mains voltage 100 - 240V~, 50 / 60Hz
Power consumption 500W
Fuse: T 5 A H 250V
Mains connector: Standard IEC receptacle

Power Supply (UL)
Mains voltage: 100 - 240V~, 50 / 60Hz
Power consumption: 500W
Fuse: T 5 A H 250V
Mains connector: Standard IEC receptacle

Power Supply (J)
Mains voltage: 100 - 240V~, 50 / 60Hz
Power consumption: 500W
Fuse T 5 A H 250V
Mains connector: Standard IEC receptacle

Power Supply (CN)
Mains voltage: 100 - 240V~, 50 / 60Hz
Power consumption: 500W
Fuse: T 5 A H 250V
Mains connector: Standard IEC receptacle

Dimensions (H x W x D): 4 7/8" x 15 3/8" x 16 3/4" (122 x 390 x 425 mm)
Weight: 15.435lb. (8 kg)
